WO2024252296 - SYSTEM FOR CANCELLING MAGNETIC FIELD
National phase entry is expected:
Publication Number
WO/2024/252296
Publication Date
12.12.2024
International Application No.
PCT/IB2024/055491
International Filing Date
05.06.2024
Title **
[English]
SYSTEM FOR CANCELLING MAGNETIC FIELD
[French]
SYSTÈME D'ANNULATION DE CHAMP MAGNÉTIQUE
Applicants **
SAFEFIELDS TECHNOLOGIES LTD.
32 Maskit Street
4673332 Herzliya, IL
Inventors
ZLOTNIK, Tal Vitaly
c/o SafeFields Technologies Ltd.
32 Maskit Street
4673332 Herzliya, IL
SHULMAN, Shaul
c/o SafeFields Technologies Ltd.
32 Maskit Street
4673332 Herzliya, IL
EINAT, Oded
c/o SafeFields Technologies Ltd.
32 Maskit Street
4673332 Herzliya, IL
Priority Data
303572
08.06.2023
IL
Application details
| Total Number of Claims/PCT | * |
| Number of Independent Claims | * |
| Number of Priorities | * |
| Number of Multi-Dependent Claims | * |
| Number of Drawings | * |
| Pages for Publication | * |
| Number of Pages with Drawings | * |
| Pages of Specification | * |
| * | |
| * | |
International Searching Authority |
EPO
* |
| Applicant's Legal Status |
Legal Entity
* |
| * | |
| * | |
| * | |
| * | |
| Entry into National Phase under |
Chapter I
* |
| Translation |
|
Recalculate
* The data is based on automatic recognition. Please verify and amend if necessary.
** IP-Coster compiles data from publicly available sources. If this data includes your personal information, you can contact us to request its removal.
Quotation for National Phase entry
| Country | Stages | Total | |
|---|---|---|---|
| China | Filing | 1323 | |
| EPO | Filing, Examination | 6420 | |
| Japan | Filing | 590 | |
| South Korea | Filing | 574 | |
| USA | Filing, Examination | 2710 |
Total: 11617 USD
The term for entry into the National Phase has expired. This quotation is for informational purposes only
Abstract[English]
A system for reducing a magnetic field in a vehicle, comprising: a passenger compartment; a three-phase electrical wiring in proximity to the passenger compartment, the three-phase electrical wiring including a first cable, a second cable, and a third cable, that when in use, generate an aggressor magnetic field in the compartment of the vehicle; a first cancellation loop having first and second legs; and a second cancellation loop having third and fourth legs, wherein the first cancellation loop includes a first non-overlapping section along at least a portion of the first cable, wherein the second cancellation loop includes a second non-overlapping section along at least a portion of the third cable, and wherein the first and second cancellation loops partially overlap along at least a portion of the second cable, to thereby facilitate cancellation of the aggressor magnetic field emanating from the three-phase electrical wiring.[French]
L'invention concerne un système de réduction d'un champ magnétique dans un véhicule, comprenant : un habitacle ; un câblage électrique triphasé à proximité de l'habitacle, le câblage électrique triphasé comprenant un premier câble, un deuxième câble et un troisième câble, qui lors de l'utilisation, génèrent un champ magnétique agresseur dans l'habitacle du véhicule ; une première boucle d'annulation ayant des première et seconde branches ; et une seconde boucle d'annulation ayant des troisième et quatrième branches, la première boucle d'annulation comprenant une première section non chevauchante le long d'au moins une partie du premier câble, la seconde boucle d'annulation comprenant une seconde section non chevauchante le long d'au moins une partie du troisième câble, et les première et seconde boucles d'annulation se chevauchant partiellement le long d'au moins une partie du second câble, pour ainsi faciliter l'annulation du champ magnétique agresseur émanant du câblage électrique triphasé.
