WO2024240512 - SUB-ASSEMBLY OF A MEDICAMENT DELIVERY DEVICE WITH ROTATABLE CAP
National phase entry is expected:
Publication Number
WO/2024/240512
Publication Date
28.11.2024
International Application No.
PCT/EP2024/062911
International Filing Date
10.05.2024
Title **
[English]
SUB-ASSEMBLY OF A MEDICAMENT DELIVERY DEVICE WITH ROTATABLE CAP
[French]
SOUS-ENSEMBLE D'UN DISPOSITIF D'ADMINISTRATION DE MÉDICAMENT AVEC CAPUCHON ROTATIF
Applicants **
SHL MEDICAL AG
Gubelstrasse 22
PO Box 7710
6302 Zug, CH
Inventors
CHIOU, Meng-Jhen
No 36 Liufu Rd, Luzhu District
Taoyuan City, 338, TW
Priority Data
23175011.8
24.05.2023
EP
Application details
| Total Number of Claims/PCT | * |
| Number of Independent Claims | * |
| Number of Priorities | * |
| Number of Multi-Dependent Claims | * |
| Number of Drawings | * |
| Pages for Publication | * |
| Number of Pages with Drawings | * |
| Pages of Specification | * |
| * | |
| * | |
International Searching Authority |
EPO
* |
| Applicant's Legal Status |
Legal Entity
* |
| * | |
| * | |
| * | |
| * | |
| Entry into National Phase under |
Chapter I
* |
| Translation |
|
Recalculate
* The data is based on automatic recognition. Please verify and amend if necessary.
** IP-Coster compiles data from publicly available sources. If this data includes your personal information, you can contact us to request its removal.
Quotation for National Phase entry
| Country | Stages | Total | |
|---|---|---|---|
| China | Filing | 1076 | |
| EPO | Filing, Examination | 4646 | |
| Japan | Filing | 531 | |
| South Korea | Filing | 575 | |
| USA | Filing, Examination | 2635 |
Total: 9463 USD
Abstract[English]
A sub-assembly of a medicament delivery device, the sub-assembly comprising: a delivery member cover, a rotator, and a cap; wherein the delivery member cover comprises a tubular proximal portion and a distal portion extending from the tubular proximal portion in a direction of a longitudinal axis L; wherein the cap comprises a cap body releasbly covering a proximal end of the tubular proximal portion of the delivery member cover; and wherein the cap body comprises a user-accessible surface and a radially directed surface adjacent to a first radially directed surface of the delivery member cover such that when a user of the medicament delivery device rotates the cap via the user-accessible surface around the longitudinal axis, the delivery member cover and the rotator are rotated around the longitudinal axis.[French]
L'invention concerne un sous-ensemble d'un dispositif d'administration de médicament, le sous-ensemble comprenant : un couvercle d'élément d'administration, un rotateur et un capuchon ; le couvercle d'élément d'administration comprenant une portion proximale tubulaire et une portion distale qui s'étend à partir de la portion proximale tubulaire dans une direction d'un axe longitudinal L ; le capuchon comprenant un corps de capuchon qui recouvre de manière libérable une extrémité proximale de la portion proximale tubulaire du couvercle d'élément d'administration ; et le corps de capuchon comprenant une surface accessible par l'utilisateur et une surface dirigée radialement adjacente à une première surface dirigée radialement du couvercle d'élément d'administration de sorte que, lorsqu'un utilisateur du dispositif d'administration de médicament fait tourner le capuchon par l'intermédiaire de la surface accessible par l'utilisateur autour de l'axe longitudinal, le couvercle d'élément d'administration et le rotateur sont tournés autour de l'axe longitudinal.
