WO2024197581 - ARRAY SUBSTRATE AND DISPLAY APPARATUS
National phase entry:
Publication Number
WO/2024/197581
Publication Date
03.10.2024
International Application No.
PCT/CN2023/084450
International Filing Date
28.03.2023
Title **
[English]
ARRAY SUBSTRATE AND DISPLAY APPARATUS
[French]
SUBSTRAT DE RÉSEAU ET APPAREIL D'AFFICHAGE
Applicants **
BOE TECHNOLOGY GROUP CO., LTD.
CHENGDU BOE OPTOELECTRONICS TECHNOLOGY CO., LTD.
Inventors
CAI, Wenzhe
DU, Mengmeng
HUANG, Yao
WANG, Rong
HE, Yi
Application details
| Total Number of Claims/PCT | * |
| Number of Independent Claims | * |
| Number of Priorities | * |
| Number of Multi-Dependent Claims | * |
| Number of Drawings | * |
| Pages for Publication | * |
| Number of Pages with Drawings | * |
| Pages of Specification | * |
| * | |
