WO2023206377 - ARRAY SUBSTRATE AND DISPLAY APPARATUS
National phase entry:
Publication Number
WO/2023/206377
Publication Date
02.11.2023
International Application No.
PCT/CN2022/090337
International Filing Date
29.04.2022
Title **
[English]
ARRAY SUBSTRATE AND DISPLAY APPARATUS
[French]
SUBSTRAT DE RÉSEAU ET APPAREIL D'AFFICHAGE
Applicants **
BOE TECHNOLOGY GROUP CO., LTD.
No.10 Jiuxianqiao Rd., Chaoyang District
Beijing 100015, CN
CHENGDU BOE OPTOELECTRONICS TECHNOLOGY CO., LTD.
No.1188 Hezuo Rd., (West Zone), Hi-tech Development Zone
Chengdu, Sichuan 611731, CN
Inventors
YU, Ziyang
No.9 Dize Rd., BDA
Beijing 100176, CN
WANG, Mengqi
No.9 Dize Rd., BDA
Beijing 100176, CN
CHEN, Wenbo
No.9 Dize Rd., BDA
Beijing 100176, CN
JIANG, Zhiliang
No.9 Dize Rd., BDA
Beijing 100176, CN
Application details
| Total Number of Claims/PCT | * |
| Number of Independent Claims | * |
| Number of Priorities | * |
| Number of Multi-Dependent Claims | * |
| Number of Drawings | * |
| Pages for Publication | * |
| Number of Pages with Drawings | * |
| Pages of Specification | * |
| * | |
| * | |
International Searching Authority |
CNIPA
* |
| Applicant's Legal Status |
Legal Entity
* |
| * | |
| * | |
| * | |
| * | |
| Entry into National Phase under |
Chapter I
* |
| Translation |
|
Recalculate
* The data is based on automatic recognition. Please verify and amend if necessary.
** IP-Coster compiles data from publicly available sources. If this data includes your personal information, you can contact us to request its removal.
Quotation for National Phase entry
| Country | Stages | Total | |
|---|---|---|---|
| China | Filing | 1330 | |
| EPO | Filing, Examination | 8356 | |
| Japan | Filing | 587 | |
| South Korea | Filing | 482 | |
| USA | Filing, Examination | 2710 |
Total: 13465 USD
The term for entry into the National Phase has expired. This quotation is for informational purposes only
Abstract[English]
An array substrate is provided. The array substrate includes a plurality of light emitting elements and a plurality ofpixel driving circuits configured to drive light emission in the plurality of light emitting elements. In a first region, transistors of multiple pixel driving circuits of the plurality of pixel driving circuits are present, and the plurality of light emitting elements are absent. In a second region, multiple light emitting elements of the plurality of light emitting elements are present, and transistors of the plurality of pixel driving circuits are absent.[French]
