WO2025154052 - SMART TYPE TURBINE FLOWMETER

National phase entry is expected:
Publication Number WO/2025/154052
Publication Date 24.07.2025
International Application No. PCT/IL2025/050039
International Filing Date 13.01.2025
Title **
[English] SMART TYPE TURBINE FLOWMETER
[French] DÉBITMÈTRE À TURBINE DE TYPE INTELLIGENT
Applicants **
TORJMAN, Niyya
MARAT TUGUSHEV
Inventors
TORJMAN, Niyya
Priority Data
310218   17.01.2024   IL
Application details
Total Number of Claims/PCT *
Number of Independent Claims *
Number of Priorities *
Number of Multi-Dependent Claims *
Number of Drawings *
Pages for Publication *
Number of Pages with Drawings *
Pages of Specification *
*
Number of Office Actions *
*
International Searching Authority
*
Recordal of a Change of the Applicant's Name/Address
*
Type of Assignment
*
Applicant's Legal Status
*
*
*
*
*
*
Entry into National Phase under
*
Patent Delivery
*
译文

* The data is based on automatic recognition. Please verify and amend if necessary.

** IP-Coster compiles data from publicly available sources. If this data includes your personal information, you can contact us to request its removal.

Quotation for National Phase entry

Country StagesTotal
China Filing, Examination, Granting2061
EPO Filing, Examination, Granting11816
Japan Filing, Examination, Granting2031
South Korea Filing, Examination, Granting1871
USA Filing, Examination, Granting5340
MasterCard Visa
Total: 23,119
Contact Us
Abstract[English] A turbine flowmeter for smart metering the discharge of the liquid flow ingoing therein and recovering the head of the measured liquid flow outgoing therefrom, in which the ingoing liquid flow is converted by the ingoing liquid flow converting assembly to one of the substantial spiral pulsing liquid flow, further oncoming onto a turbine to force it rotate impulsively at a speed proportional to the rate of the liquid flow, converging the on-going spiral pulsing liquid flow outgoing from the turbine by the convergent nozzle, diverging the on-going spiral liquid pulsing flow by divergent nozzle, further the diverging on-going spiral liquid pulsing flow is pumped by screw type pump, converted by axial fluid convertor to one of the substantial axial pulsing liquid flow, which is stopped and accumulated in the liquid head recovering chamber of the fluid collector, in which the pressure surges, caused by one of the substantial hydraulic shocks produced by the axial pulsing liquid flow impinging upon the accumulated liquid, are applied for recovering the head of the liquid, further outgoing from turbine flowmeter; where the discharge of the liquid flow is metered by the liquid flow discharge smart metering assembly, in which the hermetic measuring rotor houses the circumferentially arranged inductive coreless coils, rotates synchronously with the turbine between the magnetic stators provided with circumferentially arranged magnets for producing the circumferentially arranged alternating magnetic fluxes, when the inductive coreless coils cross it, cause to induce the electric signals, which are measured to compute the operable data associated with the liquid flow discharge, further the wireless communications of the light type code Morse enable readable the operable data, and where the magnetic stators and the hermetic measuring rotor are operated in the throat between the convergent and divergent nozzles in a path of the measurable liquid flow. Thus, the overall design has improved accuracy, smart secured metrology, liquid head recovering feature, and simple construction.[French] L'invention concerne un débitmètre à turbine destiné à mesurer de manière intelligente le flux de liquide entrant en son sein et la récupération de la hauteur du flux de liquide mesuré sortant de celui-ci, dans lequel le flux de liquide entrant est converti par l'ensemble de conversion de flux de liquide entrant en un flux de liquide pulsé sensiblement en spirale, venant en outre sur une turbine pour la forcer à tourner de manière impulsive à une vitesse proportionnelle au débit du flux de liquide, faisant converger le flux de liquide pulsé en spirale en cours sortant de la turbine par la buse convergente, faisant diverger le flux pulsé de liquide en spirale en cours par la buse divergente, le flux pulsé de liquide en spirale en cours divergent étant ensuite pompé par une pompe de type à vis, converti par un convertisseur de fluide axial en un flux de liquide pulsé axial substantiel, qui est arrêté et accumulé dans la chambre de récupération de hauteur de liquide du collecteur de fluide, dans lequel les surpressions, provoquées par l'un des chocs hydrauliques substantiels produits par le flux de liquide pulsé axial heurtant le liquide accumulé, sont appliquées pour récupérer la hauteur du liquide, sortant ensuite du débitmètre à turbine ; dans lequel le rotor de mesure hermétique loge les bobines sans noyau inductives agencées circonférentiellement, tourne de manière synchrone avec la turbine entre les stators magnétiques pourvus d'aimants agencés circonférentiellement pour produire les flux magnétiques alternatifs agencés circonférentiellement, lorsque les bobines sans noyau inductives le croisent, provoquent l'induction des signaux électriques, qui sont mesurés pour calculer les données exploitables associées au débit de liquide, en outre les communications sans fil du type code Morse lumineux permettant de lire les données exploitables, et les stators magnétiques et le rotor de mesure hermétique étant actionnés dans la gorge entre les buses convergentes et divergentes dans un trajet du flux de liquide mesurable. Ainsi, la conception globale présente une précision améliorée, une métrologie intelligente et sécurisée, une fonction de récupération de la hauteur de liquide et une construction simple.
