WO2025223945 - VEHICLE RESTRAINT WITH ENHANCED SLIDING SURFACE
National phase entry is expected:
Publication Number
WO/2025/223945
Publication Date
30.10.2025
International Application No.
PCT/EP2025/060427
International Filing Date
15.04.2025
Title **
[English]
VEHICLE RESTRAINT WITH ENHANCED SLIDING SURFACE
[French]
DISPOSITIF DE RETENUE DE VÉHICULE À SURFACE COULISSANTE AMÉLIORÉE
Applicants **
ASSA ABLOY ENTRANCE SYSTEMS AB
Inventors
WHITLEY, L. Blake
Priority Data
18/647,801
26.04.2024
US
2430418-0
22.08.2024
SE
Application details
| Total Number of Claims/PCT | * |
| Number of Independent Claims | * |
| Number of Priorities | * |
| Number of Multi-Dependent Claims | * |
| Number of Drawings | * |
| Pages for Publication | * |
| Number of Pages with Drawings | * |
| Pages of Specification | * |
| * | |
| Number of Office Actions | * |
| * | |
International Searching Authority |
EPO
* |
| Recordal of a Change of the Applicant's Name/Address |
Change of Applicant's Name and Address
* |
| Type of Assignment |
The Standard Agent's Assignment
* |
| Applicant's Legal Status |
Legal Entity
* |
| * | |
| * | |
| * | |
| * | |
| * | |
| Entry into National Phase under |
Chapter I
* |
| Patent Delivery |
Send the Letters Patent by Courier
* |
| 译文 |
|
* The data is based on automatic recognition. Please verify and amend if necessary.
** IP-Coster compiles data from publicly available sources. If this data includes your personal information, you can contact us to request its removal.
Quotation for National Phase entry
| Country | Stages | Total | |
|---|---|---|---|
| China | Filing, Examination, Granting | 2231 | |
| EPO | Filing, Examination, Granting | 10694 | |
| Japan | Filing, Examination, Granting | 2307 | |
| South Korea | Filing, Examination, Granting | 2418 | |
| USA | Filing, Examination, Granting | 4740 |

Total:
22,390
Contact Us
Abstract[English]
A vehicle restraint (100) for restraining a vehicle or trailer at a dock, the vehicle restraint comprising: a ramp assembly (120) disposed to slidably engage a rear impact guard (RIG) bar (110) of the vehicle or trailer; a vertical slide frame (106) operably coupled to the ramp assembly (120) to lower the vertical slide frame (106) from a resting height to a height of the RIG bar (110) against a bias toward the resting height responsive to the RIG bar (110) slidably engaging the ramp assembly (120) during motion of the RIG bar (110) toward the dock in a first direction; and a hook barrier (130) operably coupled to the vertical slide frame (106) to receive the RIG bar (110) and rotate to retain the RIG bar (110) responsive to the motion of the RIG bar (110) in the first direction, wherein the ramp assembly (120) comprises a top plate (200) defining a top surface (209) that faces the RIG bar (110) and is disposed at an angle relative to the first direction, and wherein the ramp assembly (120) comprises one or more instances of a contact strip (180) disposed at a portion of the top plate (200) extending away from the top surface (209) to prevent contact between the RIG bar (110) and the top surface (209).[French]
