WO2023085961 - PROTECTIVE FACCE MASK COMPRISING A CAPACITIVE SENSOR WITH EMBROIDERED SILVER PLATED POLYAMIDE ELECTRODES AND SENSITIVE POLYESTER LAYER
National phase entry is expected:
Publication Number
WO/2023/085961
Publication Date
19.05.2023
International Application No.
PCT/RS2022/000009
International Filing Date
30.05.2022
Title **
[English]
PROTECTIVE FACCE MASK COMPRISING A CAPACITIVE SENSOR WITH EMBROIDERED SILVER PLATED POLYAMIDE ELECTRODES AND SENSITIVE POLYESTER LAYER
[French]
MASQUE FACIAL PROTECTEUR COMPRENANT UN CAPTEUR CAPACITIF COMPORTANT DES ÉLECTRODES DE POLYAMIDE PLAQUÉ ARGENT BRODÉES ET UNE COUCHE DE POLYESTER SENSIBLE
Applicants **
FACULTY OF TECHNICAL SCIENCES, UNIVERSITY OF NOVI SAD
Inventors
STOJANOVIC, Goran
RADOVANOVIC, Milan
SINHA, Ankita
SIMIC, Mitar
STAVRAKIS, Adrianos
Priority Data
P-2021/1394
12.11.2021
RS
Application details
| Total Number of Claims/PCT | * |
| Number of Independent Claims | * |
| Number of Priorities | * |
| Number of Multi-Dependent Claims | * |
| Number of Drawings | * |
| Pages for Publication | * |
| Number of Pages with Drawings | * |
| Pages of Specification | * |
| * | |
| Number of Office Actions | * |
| * | |
International Searching Authority |
EPO
* |
| Recordal of a Change of the Applicant's Name/Address |
Change of Applicant's Name and Address
* |
| Type of Assignment |
The Standard Agent's Assignment
* |
| Applicant's Legal Status |
Legal Entity
* |
| * | |
| * | |
| * | |
| * | |
| * | |
| Entry into National Phase under |
Chapter I
* |
| Patent Delivery |
Send the Letters Patent by Courier
* |
| Translation |
|
* The data is based on automatic recognition. Please verify and amend if necessary.
** IP-Coster compiles data from publicly available sources. If this data includes your personal information, you can contact us to request its removal.
Quotation for National Phase entry
| Country | Stages | Total | |
|---|---|---|---|
| China | Filing, Examination, Granting | 1886 | |
| EPO | Filing, Examination, Granting | 8240 | |
| Japan | Filing, Examination, Granting | 1944 | |
| South Korea | Filing, Examination, Granting | 1525 | |
| USA | Filing, Examination, Granting | 6540 |
Total:
20,135
The term for entry into the National Phase has expired. This quotation is for informational purposes only
Contact Us
Abstract[English]
Face mask with embroidered sensor (101) with an interdigitated capacitor made by stitching of a silver-coated polyamide conductive thread on a modern embroidery machine. A disposable face mask (100) was used as the base on which the sensor was made. After making the sensor on the embroidery machine, a sensitive layer (102) is applied in between the sensor structure. This sensitive layer (103) allows the measurement of changes in humidity or temperature difference in inhaled and exhaled air. The appearance of the mask on the face of the user 104 and the position of the sensor when using the mask with the embroidered sensor are shown in fig. 1. Two different non-conductive threads were used to make the sensitive layer, based on spun polyester and extrusion-based polyester.[French]
Masque facial comportant un capteur brodé (101) ayant un condensateur interdigité constitué par la couture d'un fil conducteur en polyamide recouvert d'argent sur une machine à broder moderne. Un masque facial jetable (100) est utilisé comme base sur laquelle le capteur est fabriqué. Après la fabrication du capteur sur la machine à broder, une couche sensible (102) est appliquée entre la structure de capteur. Cette couche sensible (103) permet de mesurer les changements d'humidité ou la différence de température dans l'air inhalé et exhalé. L'aspect du masque sur le visage de l'utilisateur (104) et la position du capteur lors de l'utilisation du masque comportant le capteur brodé sont représentés sur la figure 1. Deux fils non conducteurs différents sont utilisés pour fabriquer la couche sensible, sur la base d'un polyester filé et d'un polyester basé sur l'extrusion.
