WO2024217838 - FLUIDDURCHSTRÖMBARER KÜHLER ZUM KÜHLEN VON MINDESTENS ZWEI ELEKTRISCHEN UND/ODER ELEKTRONISCHEN BAUGRUPPEN

National phase entry is expected:
Publication Number WO/2024/217838
Publication Date 24.10.2024
International Application No. PCT/EP2024/058197
International Filing Date 27.03.2024
Title **
[German] FLUIDDURCHSTRÖMBARER KÜHLER ZUM KÜHLEN VON MINDESTENS ZWEI ELEKTRISCHEN UND/ODER ELEKTRONISCHEN BAUGRUPPEN
[English] COOLING DEVICE, THROUGH WHICH FLUID CAN FLOW, FOR COOLING AT LEAST TWO ELECTRICAL AND/OR ELECTRONIC ASSEMBLIES
[French] DISPOSITIF DE REFROIDISSEMENT, À TRAVERS LEQUEL UN FLUIDE PEUT S'ÉCOULER, DESTINÉ À REFROIDIR AU MOINS DEUX ENSEMBLES ÉLECTRIQUES ET/OU ÉLECTRONIQUES
Applicants **
ROBERT BOSCH GMBH
Inventors
PAEHRISCH, Maik
HOPPE, Tobias
Priority Data
102023203651.7   20.04.2023   DE
Application details
Total Number of Claims/PCT *
Number of Independent Claims *
Number of Priorities *
Number of Multi-Dependent Claims *
Number of Drawings *
Pages for Publication *
Number of Pages with Drawings *
Pages of Specification *
*
Number of Office Actions *
*
International Searching Authority
*
Recordal of a Change of the Applicant's Name/Address
*
Type of Assignment
*
Applicant's Legal Status
*
*
*
*
*
*
Entry into National Phase under
*
Patent Delivery
*
Translation

* The data is based on automatic recognition. Please verify and amend if necessary.

** IP-Coster compiles data from publicly available sources. If this data includes your personal information, you can contact us to request its removal.

Quotation for National Phase entry

Country StagesTotal
China Filing, Examination, Granting2246
EPO Filing, Examination, Granting9039
Japan Filing, Examination, Granting2213
South Korea Filing, Examination, Granting2103
USA Filing, Examination, Granting4740
MasterCard Visa
Total: 20,341

The term for entry into the National Phase has expired. This quotation is for informational purposes only

Contact Us
Abstract[German] Die vorliegende Erfindung betrifft einen fluiddurchströmbarer Kühler (100) zum Kühlen von mindestens zwei elektrischen und/oder elektronischen Baugruppen (200). Der Kühler (100) umfasst einen Einlassbereich (115), einen Auslassbereich (116), einen Einlass (111) zum Einführen eines Fluides in den Einlassbereich (115), einen ersten Kühlbereich (107) und einen zweiten Kühlbereich (108). Der erste Kühlbereich (107) und der zweite Kühlbereich (108) sind ohne Fluidverbindung zueinander ausgebildet und in Längsrichtung (501) des Kühlers (100) zwischen einem ersten Ende (113) des Kühlers (100) und einem zweiten Ende (114) des Kühlers (100) angeordnet. Der erste Kühlbereich (107) und der zweite Kühlbereich (108) sind jeweils mit dem Einlassbereich (115) und dem Auslassbereich (116) fluidtechnisch verbunden. Der Einlassbereich (115) ist am ersten Ende (113) des Kühlers (100) und der Auslassbereich (116) am zweiten Ende (114) des Kühlers (100) angeordnet. Ferner umfasst der Kühler (100) einen Auslass (112) zum Abführen des Fluides vom Auslassbereich (116).[English] The present invention relates to a cooling device (100), through which fluid can flow, for cooling at least two electrical and/or electronic assemblies (200). The cooling device (100) comprises an inlet region (115), an outlet region (116), an inlet (111) for introducing a fluid into the inlet region (115), a first cooling region (107), and a second cooling region (108). The first cooling region (107) and the second cooling region (108) are not fluidically connected to one another and are located between a first end (113) of the cooling device (100) and a second end (114) of the cooling device (100) in the longitudinal direction (501) of the cooling device (100). The first cooling region (107) and the second cooling region (108) are each fluidically connected to the inlet region (115) and to the outlet region (116). The inlet region (115) is located at the first end (113) of the cooling device (100), and the outlet region (116) is located at the second end (114) of the cooling device (100). The cooling device (100) also comprises an outlet (112) for discharging the fluid from the outlet region (116).[French] La présente invention concerne un dispositif de refroidissement (100), à travers lequel un fluide peut s'écouler, destiné à refroidir au moins deux ensembles électriques et/ou électroniques (200). Le dispositif de refroidissement (100) comprend une région d'entrée (115), une région de sortie (116), une entrée (111) pour introduire un fluide dans la région d'entrée (115), une première région de refroidissement (107), et une seconde région de refroidissement (108). La première région de refroidissement (107) et la seconde région de refroidissement (108) ne sont pas reliées fluidiquement l'une à l'autre et sont situées entre une première extrémité (113) du dispositif de refroidissement (100) et une seconde extrémité (114) du dispositif de refroidissement (100) dans la direction longitudinale (501) du dispositif de refroidissement (100). La première région de refroidissement (107) et la seconde région de refroidissement (108) sont chacune reliées fluidiquement à la région d'entrée (115) et à la région de sortie (116). La région d'entrée (115) est située au niveau de la première extrémité (113) du dispositif de refroidissement (100), et la région de sortie (116) est située au niveau de la seconde extrémité (114) du dispositif de refroidissement (100). Le dispositif de refroidissement (100) comprend également une sortie (112) pour évacuer le fluide de la région de sortie (116).
